Cubic Mini Wood Stoves

CB-2012-SS Stainless Steel Wall Mount (Cub)

CB-2012-SS Stainless Steel Wall Mount (Cub)

Regular price $217.20 CAD
Regular price $231.75 CAD Sale price $217.20 CAD
Sale Sold out
Shipping calculated at checkout.
For certified installations: The wall mount will need to be installed a minimum of 6" off the wall it is being mounted to.
Collection
This elegant mounting option makes your installation straightforward and saves you space by safely reducing clearance to the surface it is mounted to. The wall mount is tidy, secure and compliments your wood burning stove. It also provides ample room underneath where you can stack logs or create a cozy nook for furry friend.


Features



  • Reduces clearances from the stove to the surface the wall mount is mounted to, saving square footage.

Dimensions



  • 3 11/16(9.37cm)
  • 14 3/4"(37.4cm) wide
  • 49 3/8"(125.4cm) tall when flue shield is fully extended
  • 36 7/8"(96.2cm) tall when flue shield is completely reduced

Specifics



  • You must provide a 20" clearance from a surface left or right of the stove unless a Side Shield CB-2016-SS is used.
  • Can be installed with a 1" air gap between the bottom plate and a surface below.
  • We have two other mounting options, CB-2013-SS with sliding tray and CB-2017-SS with fresh air intake.
  • Comes with 37" of flue shielding. The flue shield must run behind the pipe the entire way up the wall. If you have more than 37" of flue pipe inside, you will need enough flue shield extensions CB-2015-30-SS to cover the rest of the way.
  • Comes with side guards to prevent heat from spilling onto the surface it is mounted to.

Material



  • Stainless Steel
  • Mild Steel mounting bracket
  • 4 x 1" bushings and hardware
