Cubic Mini Wood Stoves

CB-2220-SS Grizzly Floor Mount with Rear Heat Shield (stove and pipe NOT included!)

CB-2220-SS Grizzly Floor Mount with Rear Heat Shield (stove and pipe NOT included!)

$425.36 CAD
$438.67 CAD $425.36 CAD
Sale Sold out
Shipping calculated at checkout.
Collection
This floor mount is the perfect option to reduce your rear clearance from 20’’ to just 3’’ so that you can mount your stove against a wall safely and save yourself valuable square footage. Make sure you have at least 20’’ clearance laterally or use our Side Shield CB-2216-SS to knock this clearance down to 3’’.

Stove and pipe are NOT included!



Features



  • Reduces clearances from the surface behind the stove.
  • Ideal for mounting your Grizzly stove in a tent or a space without walls.
  • Includes a small storage space for your wood.
  • The tool kit CB-3010 will be mounted to the sides of the floor mount when ordered together.

Dimensions



Floor mount:

  • The top of the stove will sit 24 1/2"(62.23cm) off the ground.
  • Height of the floor mount 14 9/16" (37cm)
  • Base plate 14 5/8"(37.1cm) wide X 14 5/16"(36.3cm) deep
  • Wood storage area 7 1/4"(18.4cm) wide X 7 3/4"(19.6cm) deep X 13 1/2"(34.29cm) tall

Rear heat shield:

  • Overall dimension 16 3/4"(42.55cm) wide
  • 20 11/16"(52.55cm) tall

Specifics



  • A Side shield CB-2216-SS may be required if a surface is within 20" laterally of the stove.
  • Flue shield CB-2015-SS will be needed if the pipe is within 9" of a surface.
  • The legs of the stove are not used when installing on the floor mount.
  • Wall mount and floor mount cannot be combined; the holes will not align.
  • Can be bolted to the floor in order to prevent it from moving around.
  • Floor does not need shielding for the heat if the stove, but protection can be installed for possible embers and ash.

Material



  • Mild Steel
  • Stainless Steel
  • Brass plated coil handles
