Cubic Mini Wood Stoves

CB-2000 Grizzly Mini Wood Stove

CB-2000 Grizzly Mini Wood Stove

Regular price Rp 8.391.000,00 IDR
Regular price Rp 11.187.000,00 IDR Sale price Rp 8.391.000,00 IDR
Sale Sold out
Shipping calculated at checkout.
Non Certified
Color

The Grizzly Mini Wood Stove CB-2000 is our non-certified model for recreational spaces of approximately 200–400 sq. ft. It is also the recommended choice for smaller spaces used in winter, with poor insulation, or with ceilings higher than 7 feet.

Compare the Cub and Grizzly before planning your setup. These stoves are not approved for residential installation. Speak with your insurer before purchasing or installing; recreational and residential insurance requirements differ. Confirm local requirements and follow the instructions for your exact model.



Features



  • Easy to install and easy to operate!
  • Secondary combustion system.
  • Removes humidity from the cabin.
  • The rail is easily removable.

Dimensions/Weight



  • 40lb
  • Measures only 13" (Wide) x 15" (High) x 12" (Depth) ( 33.02 cm x 38.1 cm x 30.48 cm ).
  • If you remove the rail you have a cooking area of 6 1/2" ( 16.51 cm ) from the flue to the edge of the plate and 13" ( 33.02 cm ) side to side.
  • Measurements for the interior firebox: 6.75" (Depth) x 7.375" (Wide) x 7.5" (Tall) (17.145 cm x 18.733 cm x 19.05 cm).

Grizzly Mini Wood Stove dimension diagram


Specifics



  • Requires a horizontal clearance of 14" ( 35.56 cm ) on the sides and 16" ( 40.64 cm) at the front of the room heater, without shielding and a vertical clearance of 40" ( 101.6 cm ).
  • Underside of stove must be shielded at all times.
  • For this non-certified setup, measure 3-inch flue-pipe clearance from the outside surface of the pipe to the combustible surface: 9 inches without shielding, or 3 inches with proper flue shielding. Shield the entire pipe run alongside the wall. Keep at least 40 inches from the stove top to the surface above; shielding does not reduce this overhead requirement.
  • The stove needs a complete flue system comprising of 3"(7.62 cm) flue pipe, 5"(12.7 cm) insulated pipe and exit kit NOT INCLUDED

Material



  • 3/16" laser cut steel top plate.
  • 1/8" laser cut steel body.
  • 1/2" thick vermiculate firebrick insulation.
  • 3/16" thick self cleaning robax glass.
  • Brass plated coil handles.
